Ajax Integration Module Wireless uartBridge

Description

Receiver module that allows you to integrate Ajax wireless detectors and devices with third-party security or smart home systems via a UART communication port. It acts as a bridge between Ajax wireless sensors (such as motion detectors, door contacts, and remote controls) and an external system that has UART support, allowing it to receive signals such as alarms, battery status, and device information in that system. The module uses Ajax Jeweller radio technology and offers encrypted wireless communication for stable and secure operation.

Specifications

• Type: Wireless integration module (receiver) for Ajax systems
• Application: Indoor
• Communication interface to external control panel: UART (57600 baud)
• Compatible Ajax devices: MotionProtect, MotionProtectPlus, DoorProtect, SpaceControl, GlassProtect, CombiProtect, FireProtect, FireProtectPlus and LeaksProtect
• Maximum number of connected devices: up to 85 wireless devices
• Range: up to approx. 2000m in open area between uartBridge and devices
• Alarm response: fast transmission of alarm data via UART to connected system
• Wireless protocol: Jeweller (several frequency bands depending on region)
• RF output power: up to 25mW (automatic adjustment)
• Data polling interval: approx. 12–300s (adjustable)
• Protection: AES encryption, jamming detection and authentication against sabotage
• Power supply: 5VDC (via UART interface from external system)
• Operating temperature: –10°C to +40°C
• Operating humidity: up to approx. 90%
• Dimensions: approx. 64 × 55 × 13mm (without antennas)
• With antennas: approx. 110 × 58 × 13mm
