Wall Socket For Combination Mounting 3-Way 16A 250V IP20 White Elko

Description

3-way wall socket for combination mounting. Safety socket with earth. The socket can be mounted in a double box together with a suitable combination frame. The socket can also be mounted on the surface together with an extension frame. Complete with 2-compartment combination frame in the Elko Plus series. Screw connection. Mounting depth 31 mm. The wall socket is not in stock but is purchased directly from the supplier, which means a slightly longer delivery time than normal.

Technical Information

• Protective contact: Earthing clips
• Number of active contacts (round): 2
• Number of active contacts (flat): 0
• Number of active contacts (square): 0
• Assembly arrangement: Basic element with central cover plate
• With signal lamp: no
• Number of socket outlets: 3
• Socket outlets phase-separated: no
• Number of modules (module system): 2
• Number of socket outlets switchable: 0
• Number of phases: 1
• Imprint/indication: None
• Connection type: Screwed terminal
• With hinged lid: No
• With enhanced contact protection: Yes
• Label space/information surface: No
• Lockable: No
• Eject-mechanism: No
• Insulated mounting: Yes
• With function lighting: No
• With orientation lighting: No
• Overvoltage protection: No
• Fault current protection: No
• With miniature fuse: No
• Special power supply: None
• Mounting method: Flush-mounted
• Type of fastening: Mounting with screw
• Anti-bacterial treatment: No
• With loop through function: No
• With on/off switch: No
• Rotated central insert: No
• Nominal current: 16 A
• Nominal voltage: 250 V
• Frequency: 50-60 Hz
• Rated fault current: 0 mA
• Suitable for degree of protection (IP): IP20

Specifications

• Color: White
• RAL-number (similar): 9010
• Metallic color: No
• Transparent: No
• Material: Plastic
• Material quality: Thermoplastic
• Halogen free: Yes
• Surface protection: Untreated
• Surface finishing: Glossy
• Device width: 142 mm
• Device height: 76 mm
• Device depth: 41 mm
• Min. depth of built-in installation box: 32 mm
