LK Manifold UNI G25/2xG20 2xc/c 50mm

Description

Intended for distribution of larger flows. The manifold has a G25 connection (outlet and int. gg) for the supply line and a G20 c/c 50 mm male gg Eurocone connection in the branch. Made of dezincification-resistant brass. Pipes AX16, AX20, AX25 and A32 can be connected to the branch with LK PressPex Press connection coupling and for certain dimensions with LK Connection coupling. The manifold can be mounted in LK UNI cabinets by removing the inserts in the bracket. LK Bracket VKF/VKF-i can be used to mount the manifold on a wall.

Specifications

• Dimension: G25 / 2xG20
• Size: 2 x c/c50mm
• Pressure/Flow/Temp: PN10, max temp +70°C (+95°C)
• Function: For tap water, heating
• Design: External x external thread
• Color: Nickel
• Surface treatment: Nickel-plated
• Material: AZH brass
• Suitable for tap water: Yes
• Suitable for heating water: Yes
• Suitable for cooling water: Yes
• Suitable for compressed air: Yes
• Suitable for glycol: Yes
• Mounting method: Surface-mounted
• Material: Brass
• Surface protection: Nickel-plated
• Dimension connection 1: Conn. 25 (1")
• Form: Through with straight branches
• Connection 1: External thread G, cylindrical (ISO 228-1)
• Connection dimension 2: Conn. 25 (1")
• Connection 2: Internal thread G, cylindrical (ISO 228-1)
• Number of branches: 2
• Number of branch directions: 1
• Dimensional branch: Conn. 20 (3/4")
• Connection branches: External thread G, cylindrical (ISO 228-1)
• Center distance between branches: 50 mm
• Difference between center distances between branches: No
• Pressure class: PN 10
• Max. medium temperature (continuous): 70 °C
• System-related: No
• With filling and draining valve: No
• With shut-off valve: Yes
• With venting: No
• With wall bracket: No
• With mounting parts: No
• With legs/feet: No
• With insulation: No
• Distributor length: 109 mm
• Distributor overall length: 109 mm
