Facade Arm Shield2 3Poles 52W 220-240V 6070lm 4000K IP66 White Scan Interlight

Description

Facade luminaire LED for wall mounting for indoor and outdoor use, consisting of: Die-cast aluminum, powder-coated polyester ISO 9227. highly resistant to UV rays and weather and wind ISO 9227. Diffuser in flat safety glass. Reflector aluminum with high efficiency and protective surface treatment. Sealing in silicone. High-power LED with high luminous flux of the latest model. Control of cooling that guarantees the function and durability of the LED lamp. Available versions with driver on-off and dimmer-connected DALI. The Extreme versions are suitable for extreme conditions, -40°C. Twilight sensors C version available on request, equipped with sensor for automatic switching on.

Technical Information

• Color temperature: 4000 - 4000K
• Nominal luminous flux: 6070 lm
• Protection class (IEC 61140): I
• Impact resistance (IK): IK09
• Light distribution: Asymmetrical
• Adapted for VDU work (EN 12464-1): No
• Number of poles: 3
• Luminaire with limited surface temperature "D" (EN 60598-2-24): No
• Maintained luminous flux at average lifetime 35,000 h (25 °C
• ambient): 95.1 %
• Maintained luminous flux at average lifetime 50,000 h (25 °C
• ambient): 93.9 %
• Maintained luminous flux at average lifetime 75,000 h (25 °C
• ambient): 91.9 %
• Bluetooth controlled: No
• CLO: No
• Dimmer function missing: Yes
• Dimming 0-10 V: No
• Dimming 1-10 V: No
• Dimming trailing edge (phasecut-off): No
• Dimming depending on driver: No
• Dimming DALI: No
• Dimming DALI-2: No
• Dimming DMX: No
• Dimming DSI: No
• Dimming leading edge (phasecut-on): No
• Dimming GPRS: No
• Dimming LineSwitch: No
• Dimming with touch: No
• Dimming with push button: No
• Dimming mains voltage modulation: No
• Dimming potentiometer (integrated): No
• Dimming programmable: No
• Dimming RF: No
• Dimming sine wave (Sine Wave Reduction): No
• Dimming manufacturer-specific: No
• Dimming Zigbee: No
• Distortion (THD): 20
• Driver: LED driver (constant current)
• Driver included: Yes
• Power factor: 0.9
• Energy efficiency class built-in lamps: A++, A+, A (LED)
• Energy efficiency class light source (EU 2019/2015): D
• Color of light adjustable: No
• Color fastness (McAdam ellipse): SDCM3
• Color rendering index (CRI/Ra): 80-89
• Photobiological safety (EN 62471): RG1
• Integrated emergency power supply: No
• Adjustable light distribution: No
• Luminous flow adjustment: No
• Protection class (IP): IP66
• Protection class (IP) front: IP66
• Compatible with Amazon Alexa: No
• Compatible with Apple HomeKit: No
• Compatible with Casambi: No
• Compatible with Google Assistant: No
• Suitable for built-in/recessed mounting: No
• Suitable for emergency lighting: No
• Suitable for pendant suspension: No
• Suitable for ramp mounting: No
• Suitable for ceiling mounting: No
• Suitable for surface mounting: Yes
• Suitable for wall mounting: Yes
• Suitable for wall mounting: Yes
• Suitable number of light sources: 1
• Conductor area: 2.5 mm²
• Light distributor/diffuser: Reflector
• Light source: LED (not replaceable)
• Light distribution angle: 40-80° (wide beam)
• Luminous efficiency: 117 lm/W
• Luminous efficiency: 117 - 117 lm/W
• Light outlet: Direct
• Rated voltage: 220-240V
• Maximum number of luminaires per circuit breaker B16: 13
• Maximum number of luminaires per circuit breaker C16: 22
• Max. system power: 52 W
• With light source: Yes
• With light sensor: No
• With air hole: No
• With motion sensor: No
• With IFTTT support: No
• Nominal lifetime L80/B10 at 25 °C: 235000 h
• Nominal ambient temperature according to IEC 62722-2-1: -20 - 25 °C
• Nominal luminous flux (IEC 62722-2-1): 6070 - 6070 lm
• Cover with insulation: No
• Grid design: None
• Voltage type: AC
• Type of wiring: Suitable for through-wiring
• Replaceable driver: Yes

Specifications

• Light color: White
• Material housing/enclosure/frame: Aluminum
• Material dome/cover: Glass (transparent)
• Surface protection housing/enclosure/frame: Powder coated
• Color housing/enclosure/frame: Anthracite
• Food Contact Material: No
• REACH: No
• ROHS: Yes
• Length: 356 mm
• Height/Depth: 230 mm
• Width: 125 mm
