Angle 32x22mm 90° PRK 406 IMI/TA

Description

TA PRK Straight coupling with FPL for 28 mm copper pipe, incl. compensation sleeve for PN 6.3 (red).

Specifications

• Outer pipe diameter connection 1: 32 mm
• Outer pipe diameter connection 2: 22 mm
• Length: 69 mm
• Connection 1: Push-in (Push-connection)
• Connection 2: Clamping ring
• Bending angle: 90 °
• Max. working pressure at 20°C (PN): 16 bar
• Material connection 1: POM (polyoxymethylene)
• Material connection 2: Brass
• Shape: Angle/Bend
• Model/Version: 3-part
• Reducing: Yes
• Eccentric: No
• System-bound: Yes
• With protective cap/plug: No
• With drain valve: No
• With air vent/bleeder: No
• FM-marked: No
• LPCB-marked: No
• ULC-marked: No
• UL-marked: No
