Ajax Magnetic Contact Plus Tilt And Shock Sensor Black

Description

Wireless door/window detector that provides enhanced protection compared to a standard magnetic contact by combining, Magnetic contact to detect opening, Tilt sensor that senses if the door/window is turned or tilted, good for example skylights or windows that open for ventilation and Shock sensor (vibration/impact) that reacts to blows, knocks or attempts to break open the door/window structure. It connects wirelessly to your Ajax hub with encrypted Jeweller communication and can also have an external input for third-party wired NC sensors. The device is designed for indoor use and is easy to install with SmartBracket bracket.

Extra Features

• External NC input: Possibility to connect a third-party wired detector
• Temperature sensor: Built-in (for ambient temperature)
• Tamper protection: Alarm in case of sabotage or removal
• In-app adjustment: Tilt activation angle and shock sensitivity can be set in the Ajax app

Specifications

• Type: Wireless magnetic contact with tilt and shock sensor
• Color: Black
• Installation: Indoor with SmartBracket
• Communication: Jeweller encrypted radio
• Range to hub: Up to approx. 1,200 m in open area
• Magnetic contact: Detects opening with two magnets (large and small) - approx. 1 cm / 2 cm magnet distance
• Tilt sensor: Detects tilt from approx. 5° and up
• Shock sensor: Built-in accelerometer that reacts to shock/vibration; sensitivity can be set in the app
• Battery: 1 × CR123A (3 V) — pre-installed
• Battery life: Up to approx. 5 years
• Operating temperature: approx. –10 °C to +40 °C
• Operating humidity: Up to approx. 75%
• Protection class: IP50 (indoors)
• Size: approx. 20 × 90 mm
